Low Speed Power Laboratory and Pilot Electric Stirrer 0.75KW

By /

This professional-grade laboratory electric stirrer delivers reliable performance with 750W input power and speeds from 0-130rpm. The unit handles processing capacity of 5-20L, making it ideal for small-batch production and experimental mixing applications in laboratory environments.

low speed power laboratory and pilot electric stirrer 0.75kw 5
low speed power laboratory and pilot electric stirrer 0.75kw 4

What It Does

The E-series vacuum heating experiment pilot dispersing mixer is designed for pre-production testing and small batch processing. It handles various materials including paints, coatings, pigments, plastics, and food products in liquid or slurry form, with capacity from 10-40L.

Key Features

  • High-performance motor with low noise operation
  • Digital CPU display with speed control
  • Electric lifting system with mobile caster base
  • Maximum speed of 3000rpm with line speed up to 33m/s
  • Double-end sealed structure for vacuum defoaming
  • Quick-release dispersing plate for easy cleaning
  • Secure barrel locking mechanism
low speed power laboratory and pilot electric stirrer 0.75kw 3
low speed power laboratory and pilot electric stirrer 0.75kw 2

How It Works

The dispersing disc rotates at high speeds to create ring-shaped material flow and strong vortex action. This generates shear impact and friction between particles for effective:

  • Rapid dispersion
  • Material dissolution
  • Uniform mixing
  • Thorough stirring

Applications

  • Suitable for materials with viscosity up to 25000 cps
  • Production capacity: 10-40L
  • Industries: Biology, medicine, food, paint, ink, adhesives, dyes, pesticides
low speed power laboratory and pilot electric stirrer 0.75kw 1
low speed power laboratory and pilot electric stirrer 0.75kw 5

Specifications

SpecificationDetail
Input Power750W
Speed Range0-130rpm
Processing Capacity5-20L
Unit Dimensions720×600×1320mm
Total Weight175kg
Lifting MethodManual lift

Packaging Information

Each unit ships with:

  • Complete built stirrer unit
  • Operation manual
  • Certificate of conformity
  • Warranty card

Note: Actual packaging contents may vary based on manufacturer’s latest standard configuration.

Frequently Asked Questions

Q: What is the difference between standard and F-model versions?
A: The standard version is non-explosion-proof, while the F-model includes explosion-proof features for hazardous environments.

Q: Can this stirrer handle high viscosity fluids?
A: Yes, the unit is designed to effectively process materials with viscosity up to 25000 cps.

Q: Is this equipment suitable for HG/T20569 standard testing?
A: Yes, this stirrer meets the requirements for HG/T20569 standard testing procedures and can be used for related laboratory tests.
